Audi A6 C6 Ac Compressor

Audi A6 C6 Ac Compressor

1.       Product Intro

Audi A6 air conditioning compressor is a variable displacement compressor, the advantage is that the power output can be automatically adjusted according to the set temperature.

The air-conditioning control system does not collect the temperature signal of the air outlet of the evaporator, but controls the compression ratio of the compressor according to the change signal of the pressure in the air-conditioning pipeline to automatically adjust the air outlet temperature.

2.       Maintenance points and methods to determine main maintenance parameters of Audi A6 C6 Ac Compressor:

(1) Before disassembly, the direction of movement of the drive belt with steel strips should be marked, because reverse installation will damage the belt.

(2) If you install a new air conditioner compressor or add lubricating oil to the compressor, be sure to turn the compressor 10 times by hand before the system runs to prevent damage to the compressor.

(3)Shaped sealing ring: low pressure joint, inner diameter is 17.2mm, thickness is 1.8mm; high pressure joint, inner diameter is 14.0mm, thickness is 1.8mm.

(4) Tightening torque: 40 Nm for low pressure joints; 30 Nm for high pressure joints.

3.       Major Specification
